Desktop sheet-fed scanner |
|
Plain paper |
| U-turn path: |
Width: 50.8 to 216mm, Length:70 to 356mm |
| Straight path: |
Width: 50.8 to 216mm, Length:53.9 to 356mm
Use Long Document mode to scan documents up to 3,000mm long |
|
| Business card |
50 x 53.9mm or larger. Vertical feeding only |
| Plastic Card |
53.9 x 85.5mm (ISO standard). Embossed cards can be scanned |
|
Plain paper |
| U-turn path: |
52 - 128g/m2 (0.06 - 0.15mm) |
| Straight path: |
40 - 209g/m2 (0.05 - 0.25mm) |
|
| Business card |
300g/m2 0.35mm or less |
| Plastic Card |
0.76mm or less |
|
Automatic sheet feeding |
|
6mm stack (including curls) or 30 sheets of 80g/m2 |
|
CMOS CIS |
|
LED (Red, Green, and Blue) |
|
Simplex / Duplex / Skip Blank Page / Folio |
|
Black and white, Error diffusion, Advanced Text Enhancement, Advanced Text Enhancement II (for Windows only), 256-level grayscale, 24-bit colour |
|
150 x 150dpi, 200 x 200dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi |
|
Simplex: |
25ppm |
| Duplex: |
50ipm |
|
Hi-Speed USB 2.0 |
|
Windows: |
ISIS / TWAIN driver, CaptureOnTouch, Presto! BizCard,Omnipage, PaperPort, eCopy PDF Pro Office, Evernote*2 |
| Mac *3: |
TWAIN driver, CaptureOnTouch, Presto! BizCard,Presto! PageManager, Evernote*2 |
|
300 x220 x156mm with the feed tray closed |
|
Approx. 2.7kg |
|
AC100 to 240V (50 / 60Hz) |
|
Scanning: |
12.8W or less |
| Sleep: |
1.8W or less |
| OFF: |
0.5W or less |
|
Temperature: |
10°C to 32.5°C |
| Humidity: |
20% to 80% RH |
|
Flatbed Scanner Unit 101/201 (DR-C225 only), Exchange Roller Kit (feed roller and retard roller) |
